Best dimming performance for dimmable LED/CFL lights, Incandescent and Halogen bulbs(120V), conveniently control and properly save energy for your lighting system. For use with up to 150 Watts of dimmable LED/CFL lamps and up to 600 Watts of Incandescent and Halogen bulbs. Features a large rocker paddle to turn lights on/off or to preset level and a fluent slider to brighten/dim lights to suit different activities.
Main Features
HOOANKE 3-way 120V Triac LED Dimmer Switch creates the perfect amount of light and the latest energy-saving technology. Features a large rocker paddle to turn lights on/off or to preset level and a fluent slider to brighten/dim lights to suit different activities, like family meals, home party, reading, watching TV, entertaining, etc.
150-watt dimmable CFL, 150-watt dimmable LED lights and 600-watt dimmable Incandescent and Halogen bulbs.
● Three-way, 120V 60Hz.
● It can be used for single-pole or 3-way applications.
● Discrete slider for precise dimmng for lights.
● Energy Saving.
● It is easy to install in less than 15 minutes.
● 12 months warranty, UL standard, ETL listed.
Specifications
Single Pole & 3 way LED Dimmer Switch for LED Lights
AC 120V 50~60Hz
150W for dimmable LED/CFL, 600W for dimmable incandescent lamp
Important notes, please read before installing.
1.Use only with 120V incandescent, CFL or LED light fixture.
2.Turn off power at circuit breaker or fuse before wiring.
3.Only 3-way switch can be used with 3-way dimmer
4.Use copper wire only
5.For supply connection, use wires rated for at least 75℃
Caution-To reduce the risk of overheating and possible damage to other equipment, do not install to control a receptacle, a motor-operated appliance or a fluorescent lighting fixture or a transformer supplied appliance.
